Effective
noise protection

Acoustic glass

Acoustic glass effectively reduce the penetration of outside noise into building interiors, providing acoustic comfort. Properly selected insulated glass units can reduce sound levels by up to several dozen of decibels.

Acoustic comfort

Ensuring adequate acoustic comfort requires effective noise protection. It is assumed that reducing the noise level by 10 dB inside the building compared to the surroundings gives the impression that it is reduced by half. Where it is not possible to eliminate the noise source, soundproof glass is used.

PRESS GLASS acoustic glass

Determination
of sound insulation

Acoustic insulated glass units are constructed on the basis of the asymmetry of the glass, their flexible bonding and the use of attenuation gases in the space between the panes. Insulated glass units - depending on the type of unit - achieve acoustic insulation within the limits of Rw=28-53 dB.

In defining the sound characteristics of building partitions, a acoustic insulation coefficient (Rw) and correction factors (C) and (Ctr) are used. They provide the average number of decibels attenuated by the partition in the range from 100 to 3150 Hz, without specifying the exact attenuation level in subsequent bands within the given frequency range. PRESS GLASS possesses certification for soundproof glass with an acoustic insulation factor ranging between 31 dB and 52 dB.

Acoustic insulation
of glazed units

Configurator
of acoustic glazed units

The easy-to-use configurator allows:

  • selection of acoustic glass using acoustic parameters
  • saving selected parameters to a PDF file
Start
configuration
European standards (EN) US Standards (ASTM)


Noise damping simulator

The intuitive-to-use simulator allows:

  • simulation of noise reduction with applications of acoustic glass;
  • comparison of the effects between different types of acoustic glass;
  • possibility to compare monolithic, single-chamber or double-chamber glazed units;
  • A selection of six distinctive noise types.
Start
configuration
European standards (EN) US Standards (ASTM)

Benefits and applications
of acoustic glass

Benefits

  • Reduction of noise levels in rooms and buildings
  • Customizable acoustic glass structure
  • Ensuring acoustic comfort in rooms

Examples of applications

  • Windows and doors of residential buildings located in noisy areas
  • Facades of commercial buildings in city centers
  • Glazing of conference rooms and offices
  • Glazing of public spaces

Specifications

List of results regarding research of acoustic glass

Standard acoustic insulation coefficients on the basis of
EN 12758 and EN 12354-3		 Structure [mm] Acoustic insulation coefficient at average frequencies [Hz]

R [dB].

 Acoustic insulation coefficient and adaptive coefficients

[dB]
125 250 500 1k 2k 4k Rw Ctr C
The table presents standard values of the weighted acoustic insulation coefficient Rw, as well as the coefficient R for different frequencies of sounds tested for the essential structures of double glazed glass units presented in glass trade magazines and technical publications. Monolithic glass
3 14 19 25 29 33 25 28 -4 -1
4 17 20 26 32 33 26 29 -3 -2
5 19 22 29 33 29 31 30 -2 -1
6 18 23 30 35 27 32 31 -3 -2
8 20 24 29 34 29 37 32 -3 -2
10 23 26 32 31 32 39 33 -3 -2
12 27 29 31 32 38 47 34 -2 0
Laminated glass

Rw– weighted acoustic insulation coefficient

Ctr – corrective coefficient for sound sources containing a large number of low frequencies, for example urban road traffic

C –  corrective coefficient for sound sources containing few low frequencies for example high speed road traffic, high speed rail traffic, children playing

 6.4 (VSG.33.1) 20 23 29 34 32 38 32 -3 -1
8.8 (VSG 44.2) 20 25 32 35 34 42 33 -3 -1
9.5 (VSG 44.4) 24 26 33 33 35 44 34 -3 -1
Insulated glass units
4/(6-16)/4 21 17 25 35 37 31 29 -4 -1
6/(6-16)/4 21 20 26 38 37 39 32 -4 -2
6/(6-16)/6 20 18 28 38 34 38 31 -4 -1
8/(6-16)/6 20 21 33 40 36 48 35 -6 -2
10/(6-16)/4 24 21 32 37 42 43 35 -5 -2
10/(6-16)/6 24 24 32 37 37 44 35 -3 -1
6.4 (VSG 33.1)/(6-16)/6 20 19 30 39 37 46 33 -5 -2
6.4 (VSG 33.1)/(6-16)/10 24 25 33 39 40 49 37 -5 -1
